26
ASSEMBLY
STEP 4 | PREMIUM KIT ASSEMBLY INSTRUCTIONS & NOTES
PART 9: PREMIUM KIT ASSEMBLY
Wing
Assemble the wing (1P) as shown using the M8
hardware provided with the kit. Tighten to 39N-m
(29 ft-lbs.).
