ID DESCRIPTION QUANTITY
34 Cable Keeper 1
PART 5: CABLE ASSEMBLY
STEP 2 | CABLE ASSEMBLY INSTRUCTIONS & NOTES
ASSEMBLY
Item 27 cable keeper must be
oriented as shown, angled 30
degrees off of the machine
centerline
