Parts List
ID
DESCRIPTION
QTY
1 Outer Frame Support 1
2 M10 Nylock Nut 8
3 User Frame 1
4 M10 Flat Washer 27
5 Wide Cupped Flange 1
6 M10 X 125L Socket Head Cap Screw 2
7 Weight Stack Frame 1
8 M10 X 20L Socket Head Cap Screw 8
9 Cable 1
10 M8 Nylock Nut 2
11 M10 Washer (Ø20 mm) 2
12 Axle 2
13 Right Arm Assembly 1
14 CAM 1
15 Spacer (Ø26.5 mm) 1
16 Swingarm 1
17 M8 Special Bolt 1
18 ROM Handle Assembly 1
19 M6 X 25L Socket Head Cap Screw 1
20 M6 Flat Washer 2
21 M6 Nylock Nut 1
22 M5 X 12L Socket Head Cap Screw 6
23 M5 Flat Washer 6
24 Cap 2
25 Threaded Sleeve 2
26 M10 X 15L Socket Head Cap Screw 6
27 M8 Flat Washer 2
28 M8 X 15L Button Head Cap Screw 1
29 M10 X 55L Button Head Cap Screw 1
30 M8 X 20L Button Head Cap Screw 1
31 Foot Plate 1
32 Spacer (Ø16 mm) 1
33 Pulley 1
34 Cable Keeper 1
35 Linkage 1
36 Axle 2
