STEP 1 | SHROUD ASSEMBLY ASSEMBLY INSTRUCTIONS & NOTES
PART 10: PLASTICS ASSEMBLY
ID DESCRIPTION QUANTITY
46 Front Shroud 1
47 Rear Shroud (Not shown) 1
ASSEMBLY
Install the weight stack shrouds as shown.
46
Position hangers in their lowest position
