Matrox Iris GTR1300 - Flow Diagram of the Auxiliary Input and Output Signals

Introducing the Matrox Iris GTR breakout board 103
Flow diagram of the auxiliary input and output signals
The following is a flow diagram of the auxiliary input and auxiliary output signals
of the Matrox Iris GTR breakout board:
Equivalent circuit only
Matrox Iris GTR
Matrox camera connector
Output
router
1
1 A breakout board switch setting controls the routing of an output
to an input.
Third-party device
Output
connector
Third-party device
(lighting controller)
ICS3
connector
Push buttons
(input-generating)
Third-party device
Input
connector
