DIGITAL BATTERY TESTER
BT90012 |
SYSTEM TEST
1. Select “SYSTEM TEST” from the main menu.
2. Turn o all vehicle accessory loads such as light, air conditioning, radio, etc.
Before starting the engine.
3. When the engine is started, one of the three results will be displayed along
with the actual reading measured.
SYSTEM TEST
xx.xx V
PRESS ENTER FOR CHARGING TEST MAKE SURE ALL LOADS ARE OFF
TURN OFF LOADS
START ENGINE
CRANKING VOLTS
xx.xx V NORMAL
CRANKING VOLTS
xx.xx V LOW
CRANKING VOLTS
NOT DETECTED
CRANKING VOLTS NORMAL
The system is showing normal draw.
Press «ENTER» to perform the charging
system test.
VOLTS BEIM ANLASSEN LOW
The cranking voltage is below normal
limits, troubleshoot the starter with
manufacturers recommended procedure.
VOLTS BEIM ANLASSEN NOT DETECTED
The cranking voltage is not detected.
4. Press «ENTER» to begin charging system test.
