Mattei AC 6000 Series User Manual

TI008G0001
3.10
Description of the Machine
Position of main parts
1 - Compressor
2 - Intake lter
3 - Electric starter
4 - Oil cooler
5 - Air cooler
6 - Oil drain
7 - Receiver/Final oil
separator
8 - Oil ller plug
9 - MAESTRO
XS
10 - Oil lter
11 - Oil level switch
12 - Main motor
13 - Fan
14 - Minimum pressure
valve
15 - Oil return valve
16 - Oil stop valve
17 - Oil temperature feeler
18 - Compressor
temperature feeler
19 - Electricity supply
20 - Pre-lter
21 - Air delivery
22 - Safety valve
23 - Thermostatic valve
904
915
916
Pos. 15
Pos. 23
918
Pos. 22
917
Pos. 16
914
913
Pos. 8
Pos. 17


















903a
