Error Message Number Possible causes Effect Remedy
Aux A Coil Error 0x8000
•
coil disconnected
•
function
disabled
•
Check wiring / connector
• Wiring issues / loose connection • Replace coil
• Current draw too high as a coil with a
different resistance is used (possible at lower
temperatures)
•
Check parameters in BODAS
service
• Coil damaged
• Check coil parameters in BODAS
service
Aux B Coil Error 0x8001
•
coil disconnected
•
function
disabled
•
Check wiring / connector
• Wiring issues / loose connection • Replace coil
• Current draw too high as a coil with a
different resistance is used (possible at lower
temperatures)
•
Check parameters in BODAS
service
• Coil damaged
• Check coil parameters in BODAS
service
Aux Control DSD
Error
0x8002
•
coil currents incorrect
•
function
disabled
•
Check wiring / connector
• coil faults • Replace coil(s)
• Paramaters incorrect
•
Check parameters in BODAS
Service
Blade Lift Left DSD
Error
0x8003
•
coil currents incorrect
•
function
disabled
•
Check wiring / connector
• coil faults • Replace coil(s)
• Paramaters incorrect
•
Check parameters in BODAS
Service
Blade Lift Left A Coil
Error
0x8004
•
coil disconnected
•
function
disabled
•
Check wiring / connector
• Wiring issues / loose connection • Replace coil
• Current draw too high as a coil with a
different resistance is used (possible at lower
temperatures)
•
Check parameters in BODAS
service
• Coil damaged
• Check coil parameters in BODAS
service
Blade Lift Left B Coil
Error
0x8005 • coil disconnected
•
function
disabled
•
Check wiring / connector
•
Wiring issues / loose connection • Replace coil
• Current draw too high as a coil with a
different resistance is used (possible at lower
temperatures)
•
Check parameters in BODAS
service
• Coil damaged
• Check coil parameters in BODAS
service
Blade Lift Right DSD
Error
0x8006
•
coil currents incorrect
•
function
disabled
•
Check wiring / connector
• coil faults • Replace coil(s)
