2/3/2020
Page 51 of 78
Calder Brothers Corporation
Model: M415XT Maintainer
M415XT
Computer Diagnostic
• Parameters incorrect
•
Check parameters in BODAS
Service
Blade Lift Right A
Coil Error
0x8007
•
coil disconnected
•
function
disabled
•
Check wiring / connector
• Wiring issues / loose connection • Replace coil
• Current draw too high as a coil with a
different resistance is used (possible at lower
temperatures)
•
Check parameters in BODAS
service
• Coil damaged
• Check coil parameters in BODAS
service
Blade Lift Right B
Coil Error
0x8008
•
coil disconnected
•
function
disabled
•
Check wiring / connector
• Wiring issues / loose connection • Replace coil
• Current draw too high as a coil with a
different resistance is used (possible at lower
temperatures)
•
Check parameters in BODAS
service
• Coil damaged
• Check coil parameters in BODAS
service
Blade Rotation DSD
Error
0x8009
•
coil currents incorrect
•
function
disabled
•
Check wiring / connector
• coil faults • Replace coil(s)
• Paramaters incorrect
•
Check parameters in BODAS
Service
Blade Rotation A
Coil Error
0x800A
•
coil disconnected
•
function
disabled
•
Check wiring / connector
• Wiring issues / loose connection • Replace coil
• Current draw too high as a coil with a
different resistance is used (possible at lower
temperatures)
•
Check parameters in BODAS
service
• Coil damaged
• Check coil parameters in BODAS
service
Blade Rotation B
Coil Error
0x800B
• coil disconnected
•
function
disabled
•
Check wiring / connector
• Wiring issues / loose connection • Replace coil
•
Current draw too high as a coil with a
different resistance is used (possible at lower
temperatures)
•
Check parameters in BODAS
service
• Coil damaged
• Check coil parameters in BODAS
service
Blade Shift DSD
Error
0x800C
•
coil currents incorrect
•
function
disabled
•
Check wiring / connector
• coil faults • Replace coil(s)
• Parameters incorrect
•
Check parameters in BODAS
Service
Blade Shift A Coil
Error
0x800D
•
coil disconnected
•
function
disabled
•
Check wiring / connector
• Wiring issues / loose connection • Replace coil
