Computer Diagnostic
• Current draw too high as a coil with a
different resistance is used (possible at lower
temperatures)
•
Check parameters in BODAS
service
• Coil damaged
• Check coil parameters in BODAS
service
Blade Shift B Coil
Error
0x800E
•
coil disconnected
•
function
disabled
•
Check wiring / connector
• Wiring issues / loose connection • Replace coil
• Current draw too high as a coil with a
different resistance is used (possible at lower
temperatures)
•
Check parameters in BODAS
service
• Coil damaged
• Check coil parameters in BODAS
service
Blade Tilt DSD Error 0x800F
•
coil currents incorrect
•
function
disabled
•
Check wiring / connector
• coil faults • Replace coil(s)
• Parameters incorrect
•
Check parameters in BODAS
Service
Blade Tilt A Coil
Error
0x8010
•
coil disconnected
•
function
disabled
•
Check wiring / connector
• Wiring issues / loose connection • Replace coil
• Current draw too high as a coil with a
different resistance is used (possible at lower
temperatures)
•
Check parameters in BODAS
service
• Coil damaged
• Check coil parameters in BODAS
service
Blade Tilt B Coil
Error
0x8011
•
coil disconnected
•
function
disabled
•
Check wiring / connector
• Wiring issues / loose connection • Replace coil
• Check parameters in BODAS
service
•
Current draw too high as a coil with a
different resistance is used (possible at lower
temperatures)
• Coil damaged
• Check coil parameters in BODAS
service
Boom A Coil Error 0x8012
•
coil disconnected
•
function
disabled
•
Check wiring / connector
• Wiring issues / loose connection • Replace coil
• Current draw too high as a coil with a
different resistance is used (possible at lower
temperatures)
•
Check parameters in BODAS
service
• Coil damaged
• Check coil parameters in BODAS
service
Boom B Coil Error 0x8013 • coil disconnected • Check wiring / connector
