Computer Diagnostic
• Wiring issues / loose connection
•
function
disabled
•
Replace coil
• Current draw too high as a coil with a
different resistance is used (possible at lower
temperatures)
•
Check parameters in BODAS
service
• Coil damaged
• Check coil parameters in BODAS
service
Boom Control DSD
Error
0x8014
•
coil currents incorrect
•
function
disabled
•
Check wiring / connector
• coil faults • Replace coil(s)
• Paramaters incorrect
•
Check parameters in BODAS
Service
Bucket A Coil Error 0x8015
•
coil disconnected
•
function
disabled
•
Check wiring / connector
• Wiring issues / loose connection • Replace coil
• Current draw too high as a coil with a
different resistance is used (possible at lower
temperatures)
•
Check parameters in BODAS
service
• Coil damaged
• Check coil parameters in BODAS
service
Bucket B Coil Error 0x8016
•
coil disconnected
•
function
disabled
•
Check wiring / connector
• Wiring issues / loose connection • Replace coil
• Current draw too high as a coil with a
different resistance is used (possible at lower
temperatures)
•
Check parameters in BODAS
service
• Coil damaged
•
Check coil parameters in BODAS
service
Bucket Control DSD
Error
0x8017
•
coil currents incorrect
•
function
disabled
•
Check wiring / connector
• coil faults • Replace coil(s)
• Parameters incorrect
•
Check parameters in BODAS
Service
CAN Engine Rx PGN
65110 Error
0x8018
•
Error from Engine
•
No effect on
functionality
•
Check engine wire harness
• Tank Information error
•
Data will not
be displayed
on the screen
•
Check Aftertreatment Diesel
exhaust liquid tank
• Check tank sensor
• Check engine ECU
0 0x8019 • Not used • NA • NA
CAN Engine Rx PGN
57344 Error
0x801A • Not Used • NA • NA
CAN Engine Rx PGN
64892 Error
0x801B • Error from Engine
•
No effect on
functionality
•
Check wire harness
