Mauldin M415XT MAINTAINER - CAN Communication Errors

2/3/2020
Page 54 of 78
Calder Brothers Corporation
Model: M415XT Maintainer
M415XT
Computer Diagnostic
• Diesel Particulate filter control error
•
Data will not
be displayed
on the screen
•
Check diesel particulate filter
• Check sensor
• Check engine ECU
CAN Engine Rx PGN
65262 Error
0x801C
•
Error from Engine
•
No effect on
functionality
•
Check wire harness
• Engine temperature error
•
Data will not
be displayed
on the screen
•
Check engine temperature
sensor
• Check sensor
• Check engine ECU
CAN Engine TSC1
Error
0x801D
•
Error from Engine
•
User cannot
change engine
speed
•
Check wire harness
• Unable to change engine speed • Engine speed controller.
• Check engine ECU
Can Rx Data HMI 1
Error
0x801E
•
CAN channel error
•
Will not be
able to change
steering
•
Check harness between display
and controller.
• Error between Display and Controller. modes
•
Make sure termination resistors
are used.
Can Rx Data HMI 2
Error
0x801F
•
CAN channel error
•
Will not be
able to change
AUX
•
Check harness between display
and controller.
• Error between Display and Controller.
implement
speed
•
Make sure termination resistors
are used.
Can Rx Data HMI 3
Error
0x8020
•
CAN channel error
•
Will not be
able to change
blade rotation
speed
•
Check harness between display
and controller.
• Error between Display and Controller.
•
Will not be
able to change
blade Shift
speed
•
Make sure termination resistors
are used.
• Will not be
able to change
blade tilt speed
• Will not be
able to change
blade lift
speed
Can Rx Data HMI 4
Error
0x8021
•
CAN channel error
•
Will not be
able to change
scarifier speed
•
Check harness between display
and controller.
• Error between Display and Controller.
•
Will not be
able to change
boom speed
•
Make sure termination resistors
are used.
