2/3/2020
Page 57 of 78
Calder Brothers Corporation
Model: M415XT Maintainer
M415XT
Computer Diagnostic
• System error
• Engine
coolant
temperature
alarm
• Hydraulic oil
temp warning
•
Engine
exhaust temp
warning
• Steering
mode pending
• Boom float
status
• Blade float
status
• Scarifier
float status
• Engine
speed override
• Skip intro
screens
• Aux
solenoid error
• Scarifier
solenoid error
• Boom
solenoid error
• Blade tilt
solenoid error
• Blade
rotation error
solenoid error
• Blade lift left
solenoid error
• Blade lift
right solenoid
error
• Parking
brake status
• Steering
valve error
Can Tx Data HMI 6
Error
0x8029 • Not Used • NA • NA
Low Battery 0x802A • Low battery
•
Machine
could stop if
•
Check battery voltage.
