Calder Brothers Corporation
Model: M415XT Maintainer
M415XT
Computer Diagnostic
Can Tx Data HMI 1
Error
0x8024
•
CAN channel error
•
No effect on
machine
•
Check harness between display
and controller.
• Error between Display and Controller.
•
Make sure termination resistors
are used
Can Tx Data HMI 2
Error
0x8025
•
CAN channel error
•
Unable to
view current
bucket angle
•
Check harness between display
and controller.
• Error between Display and Controller.
•
Will not be
able to see
engine data
•
Make sure termination resistors
are used
(engine hours,
engine load,
fuel level)
Can Tx Data HMI 3
Error
0x8026
•
CAN channel error
•
Unable to
view engine
def level
•
Check harness between display
and controller.
• Error between Display and Controller.
•
Unable to
view steering
mode
•
Make sure termination resistors
are used
• Unable tot
view aux speed
Can Tx Data HMI 4
Error
0x8027
•
CAN channel error
•
Will be
unable to use
last stored
engine
•
Check harness between display
and controller.
• Error between Display and Controller. RPM setting
•
Make sure termination resistors
are used
Can Tx Data HMI 5
Error
0x8028
• CAN channel error
Will be unable
to view the
following items
•
Check harness between display
and controller.
• Error between Display and Controller.
•
Engine
coolant temp
warning
•
Make sure termination resistors
are used
• Engine oil
pressure
warning
• Engine def
level low
warning
• Neutral
position front
axle
• Neutral
position rear
axle
• Emergency
stop
