2/3/2020
Page 59 of 78
Calder Brothers Corporation
Model: M415XT Maintainer
M415XT
Computer Diagnostic
Joystick 1 Axis 3
Error
• CAN communication error
•
Machine
implement
functionality
disabled
•
Replace if necessary
• Wiring harness damaged • Check wiring harness,
• Ensure termination resistors used
in wiring
harness
Joystick 1 Axis 4
Error
0x8036
•
Joystick damaged
•
Machine
implement
functionality
disabled
•
Check joystick
• CAN communication error • Replace if necessary
• Wiring harness damaged • Check wiring harness,
• Ensure termination resistors used
in wiring
harness
Joystick 1 Axis 5
Error
0x8037
•
Joystick damaged
•
Machine
implement
functionality
disabled
•
Check joystick
• CAN communication error • Replace if necessary
• Wiring harness damaged • Check wiring harness,
• Ensure termination resistors used
in wiring
harness
Joystick 2 Error 0x8038
•
Joystick damaged
•
Machine
implement
functionality
disabled
•
Check joystick
• CAN communication error • Replace if necessary
• Wiring harness damaged • Check wiring harness,
• Ensure termination resistors used
in wiring
harness
Joystick EJM2 Error 0x8039
•
Joystick damaged
•
Machine
implement
functionality
disabled
•
Check joystick
• CAN communication error • Replace if necessary
• Wiring harness damaged • Check wiring harness,
• Ensure termination resistors used
in wiring
harness
Motor 1 Control
Error
0x803A • Not Used • NA • NA
Motor 2 Control
Error
0x803B • Not Used • NA • NA
Parking Brake Error 0x803C
•
Parking brake damaged
•
Machine will
not drive
•
Check switch
• Wiring issue • Check wiring harness
• Parking brake disconnected
Parking Brake Error 0x803D • Not used • NA • NA
Pedal Comm. Error 0x803E
•
Pedal error
•
Machine will
not drive
•
Check pedal
• Wiring harness issue • Replace pedal if necessary
• Pedal damaged • Check wiring harness
• Pedal disconnected
Pressure Sensor
Blade 1A Error
0x803F • Not Used • NA • NA
Pressure Sensor
Blade 1B Error
0x8040 • Not Used • NA • NA
