2/3/2020
Page 60 of 78
Calder Brothers Corporation
Model: M415XT Maintainer
M415XT
Computer Diagnostic
Pressure Sensor
Blade 2A Error
0x8041 • Not Used • NA • NA
Pressure Sensor
Blade 2B Error
0x8042 • Not Used • NA • NA
Pressure Sensor
Boom 1A Error
0x8043 • Not Used • NA • NA
Pressure Sensor
Boom 1B Error
0x8044 • Not Used • NA • NA
Pressure Sensor
Pump 1 Ma Error
0x8045
•
Pump pressure sensor error
•
ePOR
disabled
•
Check sensor
• Sensor damaged • eEP disabled • Check wiring harness
• Wiring issue
•
pump goes
into ET mode
•
Replace sensor if necessary
• Connection issue
• Check connection
Pressure Sensor
Pump 1 Mb Error
0x8046
•
Pump pressure sensor error
•
ePOR
disabled
•
Check sensor
• Sensor damaged • eEP disabled • Check wiring harness
• Wiring issue
•
pump goes
into ET mode
•
Replace sensor if necessary
• Connection issue
• Check connection
Pressure Sensor
Pump 2 Ma Error
0x8047
•
Pump pressure sensor error
•
ePOR
disabled
•
Check sensor
• Sensor damaged • eEP disabled • Check wiring harness
• Wiring issue
•
pump goes
into ET mode
•
Replace sensor if necessary
• Connection issue
• Check connection
Pressure Sensor
Pump 2 Mb Error
0x8048
•
Pump pressure sensor error
•
ePOR
disabled
•
Check sensor
• Sensor damaged • eEP disabled • Check wiring harness
• Wiring issue
•
pump goes
into ET mode
•
Replace sensor if necessary
• Connection issue
• Check connection
Pressure Sensor
Scarr 1A Error
0x8049 • Not Used • NA • NA
Pressure Sensor
Scarr 1B Error
0x804A • Not Used • NA • NA
Pump 1A Angle
Error
0x804B • Not Used • NA • NA
Pump 1A Control
Error
0x804C • Not Used • NA • NA
Pump 1A Out Error 0x804D
• coil disconnected
•
Drive
Disabled
•
Check wiring / connector
• Wiring issues / loose connection • Replace coil
•
Current draw too high as a coil with a
different resistance is used (possible at lower
temperatures)
• Coil damaged
