2/3/2020
Page 61 of 78
Calder Brothers Corporation
Model: M415XT Maintainer
M415XT
Computer Diagnostic
Pump 1A Out HS
Error
0x804E
•
coil disconnected
•
Drive
Disabled
•
Check wiring / connector
• Wiring issues / loose connection • Replace coil
• Current draw too high as a coil with a
different resistance is used (possible at lower
temperatures)
• Coil damaged
Pump 1B Angle
Error
0x804F • Not Used • NA • NA
Pump 1B Control
Error
0x8050 • Not Used • NA • NA
Pump 1B Out Error 0x8051
•
coil disconnected
•
Drive
Disabled
•
Check wiring / connector
• Wiring issues / loose connection • Replace coil
• Current draw too high as a coil with a
different resistance is used (possible at lower
temperatures)
• Coil damaged
Pump 1B Out HS
Error
0x8052
•
coil disconnected
•
Drive
Disabled
•
Check wiring / connector
• Wiring issues / loose connection • Replace coil
• Current draw too high as a coil with a
different resistance is used (possible at lower
temperatures)
• Coil damaged
Pump 2A Angle
Error
0x8053 • Not Used • NA • NA
Pump 2A Control
Error
0x8054 • Not Used • NA • NA
Pump 2A Out Error 0x8055
•
coil disconnected
•
Drive
Disabled
•
Check wiring / connector
• Wiring issues / loose connection • Replace coil
• Current draw too high as a coil with a
different resistance is used (possible at lower
temperatures)
• Coil damaged
Pump 2A Out HS
Error
0x8056
•
coil disconnected
•
Drive
Disabled
•
Check wiring / connector
• Wiring issues / loose connection • Replace coil
• Current draw too high as a coil with a
different resistance is used (possible at lower
temperatures)
• Coil damaged
Pump 2B Angle
Error
0x8057 • Not Used • NA • NA
Pump 2B Control
Error
0x8058 • Not Used • NA • NA
Pump 2B Out Error 0x8059
•
coil disconnected
•
Drive
Disabled
•
Check wiring / connector
• Wiring issues / loose connection • Replace coil
