2/3/2020
Page 62 of 78
Calder Brothers Corporation
Model: M415XT Maintainer
M415XT
Computer Diagnostic
• Current draw too high as a coil with a
different resistance is used (possible at lower
temperatures)
• Coil damaged
Pump 2B Out HS
Error
0x805A
•
coil disconnected
•
Drive
Disabled
•
Check wiring / connector
• Wiring issues / loose connection • Replace coil
• Current draw too high as a coil with a
different resistance is used (possible at lower
temperatures)
• Coil damaged
Rear Steer Angle
Error
0x805B
•
Sensor damaged
•
Unable to
change
steering mode
•
Check sensor
• Wire harness issue • Replace sensor if needed
• Check wiring harness
Reverse Alarm Error 0x805C
•
Sensor damaged
•
Reverse
alarm will not
sound OR
•
Check sensor
• Wire harness issue
•
Reverse
alarm will be
always on
•
Replace sensor if needed
• Check wiring harness
Tool Bar A Coil
Error
0x805D
•
coil disconnected
•
Function
Disabled
•
Check wiring / connector
• Wiring issues / loose connection • Replace coil
• Current draw too high as a coil with a
different resistance is used (possible at lower
temperatures)
• Coil damaged
Tool Bar B Coil Error 0x805E
•
coil disconnected
•
Function
Disabled
•
Check wiring / connector
• Wiring issues / loose connection • Replace coil
• Current draw too high as a coil with a
different resistance is used (possible at lower
temperatures)
• Coil damaged
Scarifier Control
DSD Error
0x805F
•
coil currents incorrect
•
Function
disabled
•
Check wiring / connector
• coil faults • Replace coil(s)
• Paramaters incorrect
•
Check parameters in BODAS
Service
Steering Detent Coil
Error
0x8060
•
coil disconnected
•
Unable to
change
steering
modes
•
Check wiring / connector
• Wiring issues / loose connection • Replace coil
•
Current draw too high as a coil with a
different resistance is used (possible at lower
temperatures)
• Coil damaged
Steering Mode 2
Coil Error
0x8061
•
coil disconnected
•
Unable to
change
•
Check wiring / connector
• Wiring issues / loose connection • Replace coil
