2/3/2020
Page 63 of 78
Calder Brothers Corporation
Model: M415XT Maintainer
M415XT
Computer Diagnostic
• Current draw too high as a coil with a
different resistance is used (possible at lower
temperatures)
steering
modes
• Coil damaged
Steering Mode 3
Coil Error
0x8062
•
coil disconnected/ damaged
•
Unable to
change
steering
modes
•
Check wiring / connector
• Wiring issues / loose connection • Replace coil
• Current draw too high as a coil with a
different resistance is used (possible
at lower temperatures)
Invalid Pedal Data 0x8063
•
Pedal wiring issue
•
Drive
disabled
•
Check pedal
• Damaged pedal • Replace pedal if necessary
• Wiring harness fault • Check wiring
• Pedal disconnected
eEP Logic Left
Param out of rng
0x8064 • eEP parameters out of range
•
eEP disabled
•
check parameters in BODAS
service
• pump goes
intp ET mode
eEP Logic Left Input
out of rng
0x8065 • eEP inputs out of range
•
eEP disabled • check pump pressure sensors
• pump goes
intp ET mode
•
check pump angle sensors
• check wiring harness
eEP Logic Left
Tracking Lost
0x8066
•
difference between pump desired angle
and actual angle exceeds 15%
•
eEP disabled • check pump
• pump damaged
•
pump goes
intp ET mode
•
check angle sensor
• angle sensor damamged
• check wiring harness
• angle sensor disconnected
• check connector to angle sensor
• wiring harness issue
eEP Logic Right
Param out of
0x8067 • eEP parameters out of range
•
eEP disabled
•
check parameters in BODAS
service
rng
• pump goes
intp ET mode
eEP Logic Right
Input out of rng
0x8068 • eEP inputs out of range
•
eEP disabled • check pump pressure sensors
• pump goes
intp ET mode
•
check pump angle sensors
• check wiring harness
eEP Logic Right
Tracking Lost
0x8069
•
difference between pump desired angle
and actual angle exceeds 15%
•
eEP disabled • check pump
• pump damaged
•
pump goes
intp ET mode
•
check angle sensor
• angle sensor damamged
• check wiring harness
• check connector to angle sensor
•
angle sensor disconnected
•
ensure sensors are connected to
correct sockets
• wiring harness issue
•
ensure solenoids are connected
to
