Calder Brothers Corporation
Model: M415XT Maintainer
M415XT
Computer Diagnostic
• sensor wired backwords
• sensor connected to wrong port
• pump solenoids connected wrong
Left Angle snsr
param out of rng
0x806A • angle sensor parameters out of range
•
eEP disabled
•
check parameters in BODAS
service
• pump goes
intp ET mode
Left Angle snsr
input out of rng
0x806B • input voltage out of range
•
eEP disabled • check sensor
• pump goes
intp ET mode
•
check connection
• check wiring harness
Left Angle snsr
output out of rn
0x806C • Sensor output out of range
•
eEP disabled • check sensor
• pump goes
intp ET mode
•
check connection
• check wiring harness
Left angle snsr
redund. error
0x806D
•
sensor issue • eEP disabled • check sensor
• sensor damaged
•
pump goes
intp ET mode
•
check connection
• sensor disconnected
• check wiring harness
• wiring harness issue
Righ Angle snsr
param out of
0x806E • angle sensor parameters out of range
•
eEP disabled
•
check parameters in BODAS
service
rng
• pump goes
intp ET mode
Righ Angle snsr
input out of rng
0x806F • input voltage out of range
•
eEP disabled • check sensor
• pump goes
intp ET mode
•
check connection
• check wiring harness
•
Righ Angle snsr
output out of rn
0x8070 • Sensor output out of range
•
eEP disabled • check sensor
• pump goes
intp ET mode
•
check connection
• check wiring harness
Right angle snsr
redund. error
0x8071
•
sensor issue • eEP disabled • check sensor
• sensor damaged
•
pump goes
intp ET mode
•
check connection
• sensor disconnected
• check wiring harness
• wiring harness issue
Left Pres diff param
out of rng
0x8072 • incorrect parameter set
•
eEP disabled
•
Check parameters in BODAS
service
• pump goes
intp ET mode
Left Pres input out
of range
0x8073
•
sensor input out of range • eEP disabled • check sensor
• incorrect parameters
•
pump goes
intp ET mode
•
check wiring harness
• sensor damaged
• check pump
• sensor disconnected
