Calder Brothers Corporation
Model: M415XT Maintainer
M415XT
Computer Diagnostic
• pimp damaged
Right Pres diff
param out of rng
0x8074 • incorrect parameter set
•
eEP disabled
•
Check parameters in BODAS
service
• pump goes
intp ET mode
Right Pres input out
of range
0x8075
•
sensor input out of range • eEP disabled • check sensor
• incorrect parameters
•
pump goes
intp ET mode
•
check wiring harness
• sensor damaged • check pump
• sensor disconnected
• pimp damaged
Left Pres Prop
param out of rng
0x8076 • incorrect parameter
•
eEP disabled
•
Check parameters in BODAS
service
• pump goes
intp ET mode
Left Pres Prop input
out of rng
0x8077
•
sensor input out of range • eEP disabled • check sensor
• incorrect parameters
•
pump goes
intp ET mode
•
check wiring harness
• sensor damaged • check pump
• sensor disconnected
• pimp damaged
Right Pres Prop
param out of rng
0x8078 • incorrect parameter
•
eEP disabled
•
Check parameters in BODAS
service
• pump goes
intp ET mode
Right Pres Prop
input out of rng
0x8079
•
sensor input out of range • eEP disabled • check sensor
• incorrect parameters
•
pump goes
intp ET mode
•
check wiring harness
• sensor damaged • check pump
• sensor disconnected
• pimp damaged
Sensor cal. param
out of rng
0x807A • incorrect parameter
•
eEP disabled
•
Check parameters in BODAS
service
• pump goes
intp ET mode
Sensor cal. input
out of rng
0x807B
•
sensor input out of range • eEP disabled • check sensor
• incorrect parameters
•
pump goes
intp ET mode
•
check wiring harness
• sensor damaged • check pump
• sensor disconnected
• pimp damaged
Boom Float Coil
Error
0x807C
•
coil disconnected
•
Functionality
disabled
•
Check wiring / connector
• Wiring issues / loose connection • Replace coil
• Current draw too high as a coil with a
different resistance is used (possible at lower
temperatures)
• Coil damaged
Beacon Output
Error
0x807D
•
Wiring error
•
Functionality
disabled
•
Check wiring / connector
• Sensor disconnected • Replace sensor
