2/3/2020
Page 66 of 78
Calder Brothers Corporation
Model: M415XT Maintainer
M415XT
Computer Diagnostic
• Sensor damaged
Work Light Output
Error
0x807E • Wiring error
•
Functionality
disabled
•
Check wiring / connector
•
Sensor disconnected
• Replace sensor
• Sensor damaged
Blade Float Output
Error
0x807F
•
coil disconnected
•
Functionality
disabled
•
Check wiring / connector
• Wiring issues / loose connection • Replace coil
• Current draw too high as a coil with a
different resistance is used (possible at lower
temperatures)
• Coil damaged
EP Mode Disabled 0x8080 • Pressure sensor error
•
ePOR
disabled
•
Check wiring
• Torque
mode disabled
•
Check pressure sensors
• Pump
operates in ET
mode
ePOR Disabled 0x8081 • Pressure sensor error
•
ePOR
disabled
•
Check wiring
• Torque
mode disabled
•
Check pressure sensors
• Pump
operates in ET
mode
CAN 1 Error 0x8082
•
CAN channel disconnected
•
BODAS
Service
disabled
•
Check wiring
• No termination resistance • Add termination resistor
• Wiring issue
CAN 2 Error 0x8083
•
CAN channel disconnected
•
Machine
functionality
disabled
•
Check wiring
• No termination resistance • Add termination resistor
• Wiring issue
CAN 3 Error 0x8084
•
CAN channel disconnected
•
Bucket
levelling
disabled
Display CAN 2
disabled
•
Check wiring
• No termination resistance • Add termination resistor
• Wiring issue
Front Speed Sensor
Error Pin 1
0x8085
•
Sensor error
•
Speed will
not be
displayed on
the display
•
Check sensor
• Sensor damaged • Replace if necessary
• Sensor disconnected • Check wiring
• Wiring fault
Front Speed Sensor
Error Pin 2
0x8086
•
Sensor error
•
Speed will
not be
displayed on
the display
•
Check sensor
• Sensor damaged • Replace if necessary
• Sensor disconnected • Check wiring
• Wiring fault
Front Motor HS 0x8087 • coil disconnected • Check wiring / connector
