MAULE MX-7-180A - Power Plant Limits

MAULE AEROSPACE TECHNOLOGY, INC.
2.2 POWER PLANT LIMITS:
Engine:
Engine Limits:
Propeller:
Fuel:
Engine Instrument Markings:
Cylinder Head Temperature:
Oil Temperature:
Oil Pressure:
Manifold Pressure
Fuel Pressure
Tachometer:
FAA APPROVED
DATE:
MAULE AEROSPACE TECHNOLOGY, INC.
AIRPLANE FLIGHT MANUAL
MAULE MX-7-180A
Lycoming O-360-C1F or 0-360-C4F
180 hp @ 2700 rpm, Full Throttle Continuous
Sensenich Fixed Pitch 76EM8S5-0-
56 (76" Dia.)
100/100LL Minimum Grade Aviation Gasoline
Engine Instrument Markings:
Cylinder Head Temperature:
Green Arc -
Normal Operating Range,
200°F - 435
°
Red Radial -
Operating Limit, 500
Oil Temperature:
Green Arc -
Normal Operating Range,
140°F - 245
°
Red Radial -
Operating Limit, 245
Oil Pressure:
Green Arc -
Normal Operating Range,
55 to 95 PSI
Yellow Arc -
Caution Range, 25 to 55 PSI
and 95 to 115
Red Radial -
Minimum Operating Pressure,
25 PSI
Red Radial -
Maximum Operating Pressure,
115 PSI
Manifold Pressure
Green Arc -
Normal Operating Range,
14.5 to 29 ins. of Mercury
Fuel Pressure
Green Arc -
Normal Operating Range,
0.5 to 8 PSI
Red Radial -
Minimum Pressure, 0.5
Red Radial -
Maximum Pressure, 8.0
Green Arc -
Normal Operating Range,
(0-360-
C1F) 2350
Green Arc -
Normal Operating Range,
(0-360-
C4F) 2000
Red Radial -
Maximum RPM, 2700 RPM
Red Arc -
Avoid Continuous Operation,
(0-360-
C1F) 2150
PAGE 4
SECTION II
LIMITATIONS
180 hp @ 2700 rpm, Full Throttle Continuous
56 (76" Dia.)
100/100LL Minimum Grade Aviation Gasoline
Normal Operating Range,
°
F
Operating Limit, 500
°F
Normal Operating Range,
°
F
Operating Limit, 245
°F
Normal Operating Range,
Caution Range, 25 to 55 PSI
and 95 to 115
PSI
Minimum Operating Pressure,
Maximum Operating Pressure,
Normal Operating Range,
14.5 to 29 ins. of Mercury
Normal Operating Range,
Minimum Pressure, 0.5
PSI,
Maximum Pressure, 8.0
PSI
Normal Operating Range,
C1F) 2350
- 2700 RPM
Normal Operating Range,
C4F) 2000
- 2700 RPM
Maximum RPM, 2700 RPM
Avoid Continuous Operation,
C1F) 2150
- 2350 RPM
