Max ER-2700 - DISPLAY AND KEYBOARD

- 5 -
PARTS DESCRIPTIONS
HOW TO OPEN AND CLOSE FRONT COVER
DISPLAY AND KEYBOARD
DISPLAY LAYOUT
(A) symbol appears Daylight Saving Time activates.
(B) symbol appears Daylight Saving Time activates.
(C) symbol appears during settings are protected by password.
(D) symbol appears while you set IN/OUT program for Special day.
Pull as illustrated above. Remove a front cover. Push as illustrated above.
Time card insertion slot
Display
External ke
y
Wall mountin
g
plate
Front cove
r
