Max SuperLocator SN438J User Manual

1
1. SPECIFICATIONS AND TECHNICAL DATA
1. NAME OF PARTS (SEE Fig.1)
2. TOOL SPECIFICATIONS
3. FASTENER SPECIFICATIONS
MAX strongly recommends the use of hardened nails in the tools.
ENGLISH
OPERATING INSTRUCTIONS MANUAL
1 Frame 7 Grip
2 Cylinder Cap 8 Exhaust Cover
3 Contact Arm 9 Pusher
4 Nose 0 Rafter Hook
5 Magazine
6 Trigger
PRODUCT NO. SN438J
HEIGHT 10-1/2" 264 mm
WIDTH 4-1/4" 107 mm
LENGTH 12-1/4" 310 mm
WEIGHT 5. lbs. 2.3 kg
LOADING CAPACITY 29 Nails
RECOMMENDED
OPERATING PRESSURE
70 to 100 p.s.i.
5 to 7 bar
AIR CONSUMPTION
0.074 ft3 at 90 p.s.i. operating pressure
2.1L at 6.9 bar operating pressure
PRODUCT NO. SN438J
NAIL LENGTH
1-1/2"
38 mm
SHANK DIAMETER
.131" / .148"
3.3 / 3.8 mm
SHANK TYPE Smooth
HEAD DIAMETER
0.280"
7.1 mm
COLLATION ANGLE 34 degree
HEAD Full round head
