Player Overview
Key control and Key functions:
1 2 3 4 5 6 7
5. UP BUTTON( ): Functional selection button and
rotate 90 degrees counter-clockwise.
8
6. DOWN BUTTON( ): Functional selection button
9
and rotate 90 degrees clockwise.
10
7. STANDBY BUTTON: Used to power on and off the
11
Digital Photo Frame.
8. DC 5V:Input for the DC Power Adapter into the DPF.
9. ON/OFF: Used to power on and off the Digital Photo
Frame.
12
1. ENTER BUTTON:
Used to confirm options.
and
10. SD/MMC/MS CARD: The socket for DPF player to
Pause or Play.
connect the SD/MMC or MS memory card.
2. MENU BUTTON: Press MENU key to return to last
11. USB: Connect to a USB drive.
interface. Use for setup programs, then by pressing
long (over 2 seconds) enter to execute the command.
12. Bracket jack.
3. RIGHT SHIFT BUTTON( W ): Right cursor selection
and next photo.
4. LEFT SHIFT BUTTON( X ): Left cursor selection
and previous photo.
6
