continued on next page
Cleaning and Installing
Seat Pad Set
66
65
7
8
9
Turn Seat Over
Locate buckle’s metal retainer
on bottom of shell.
Rotate Metal Retainer
and Push It Up Through
Shell and Pad
From Top of Seat,
Pull Buckle and Buckle
Cover Out of Shell
And Pad
Starting From Bottom
of Child Restraint, Slip
Pad on Shell and Wrap
Around the Top of Shell
1
Machine wash separately with cold water on a gentle
cycle. Make sure harness covers are closed so fasten-
ing strips are not exposed. Do not use bleach. Tumble
dry separately for 10-12 minutes on low heat. Remove
immediately.
Cleaning Harness Strap
Spot clean using warm sudsy water and damp cloth.
WARNING: Do not use child restraint without
the seat pad. Failure to do this can result in serious
injury or death.
Cleaning Pads and Accessories
To Next Page
