7
Battery Charging Input
5 V/1.5 A
Input Voltage
12 V (9-35 V)
Power Consumption
500 mA (LCD on with default brightness, Wi-Fi
on) @3.7 V
Operating Temp.
-10 to 60°C(14 to 140°F)
Storage Temp.
-20 to 70°C (-4 to 158°F)
Operating Humidity
5% - 95% non-condensing
Housing
Strong plastic housing with protective rubber
boot
Dimensions (W x H x D)
237.8 mm (9.4”) x 148.6 mm (5.9”) x 35.5 mm
(1.4”)
Net Weight
788 g (2.42 lb.)
Supported Automotive
Protocols
ISO9142-2, ISO14230-2,ISO15765, K/L-Line,
Flashing Code, SAE-J1850 VPW, SAE-J1850
PWM, ISO11898(Highspeed, Middlespeed,
Lowspeed and Singlewire CAN,fault-tolerant
CAN), SAE J2610,GM UART,UART Echo Byte
Protocol, Honda Diag-H Protocol, TP2.0, TP1.6
Accessory Kit
Main Cable
The Display Tablet can be powered through the Main Cable when
connected to an OBD II/EOBD compliant vehicle. The Main Cable
connects the Display Tablet to the vehicle’s data link connector (DLC).
