3 Getting Started
Make sure the Display Tablet has sufficient power or is connected to the
DC power supply (see 0 Power Sources on page 6).
NOTE
The images and illustrations depicted in this manual may differ from the actual
ones.
Powering Up
Long press the Lock/Power button on the top right of the Display Tablet to
switch the unit on. The power LED light will illuminate green. The system
boots up, and shows the lock screen. Sliding the Lock icon to unlock and
enter the MaxiCheck Job Menu (Figure 3-1):
Figure 3-1 Sample MaxiCheck MX808 Job Menu
1. Application Buttons
2. Locator and Navigation Buttons
3. Status Icons
