26
entry, through which you can perform generic OBD II or EOBD tests. See 0
Generic OBD II Operations on page 44 for details.
Navigation
This section describes how to navigate the Diagnostics interface and select
test options.
Diagnostics Screen Layout
The diagnostic screens typically include four sections (错误!未找到引用源。).
1. Diagnostics Toolbar
2. Status Information Bar
3. Main Section
4. Functional Buttons
Diagnostics Toolbar
The Diagnostics Toolbar contains a number of buttons that allow you to print
or save the displayed data and make other controls. The table below provides
a brief description for the operations of the Diagnostics Toolbar buttons.
Figure 4-8 Sample Diagnostics Screen
