14
ROUTINE MAINETNANCE
MOTOR SUPPORT (D)
It is located under the upper cover. For the cleaning at first we recommend disconnecting the
device. Use only a wet cloth. Do not use direct water jets (i.e.: shower, tap, etc.).
DO NOT INCLINE THE MACHINE MORE THAN 45°.
FILTER AND SEPARATOR
The plastic filter (C) is fixed on the motor support (D). To remove it, just turn it anticlockwise. Wash
it with water. Once the filter has been removed you can see the “conic molecular separator”(A).
This separator must be periodically washed with water. To remove it loosen the knurled screw
(B) and take it out from its seat. Pay attention when inserting it again since it is provided with a
fastening seat. Turn the knurled screw clockwise by using your hands and without fastening too
much. Never use the machine when the plastic filter is not inserted.
A. Molecular separator.
B. Knurled screw.
C. Filter.
D. Motor support.
A
p
r
i
C
h
i
u
d
i
C
A
B
D
