Maxima ATHENA 6 - Sponge Filter

15
SPONGE FILTER
The filter cover (A) is located in the rear part of the machine and can be removed by unscrewing
the stop nut (F) (fig.17-18).
Once the filter cover has been removed, you can reach the silencer filter (C) which is located in the
motor air outlet (D). We recommend cleaning it periodically by washing it with water.
A. Filter cover.
B. Coupling pin
C. Silencer filter
D. Air outlet
E. Washer
F. Stop nut
FIG.18
FIG.17
E
F
A
C
B
D
