8. Hydraulic Trolley
8.1. Lifting
Put down the handlebar, press it up & down several times, in order to lift the column at 30 ~
40mm height from the ground. Refer to Fig. 13, 14.
Lifting b
racket
hydraulic
tr
olle
y
handleb
ar
Fig. 13 Fig. 14
8.2. Movement
Put up the release bar flatly, move the holding fork arm under the vehicle tire by pushing the
handlebar.
8.3. Falling
Put up the release bar upwards (Fig.15), lower the column to the ground slowly.
Note:
To avoid crushing hands, make sure the doors of the electric control boxes being closed before
putting up the release bar!
Release b
ar
Fig.
15
