Maxima ML4030B - The Electronics; Control System Overview

- 5 -
Range
Model
h1(mm)
h2(mm)
A
1345
1895
B
850
1350
C
400
550
ML4030B Heavy Duty Column Lift Axle Stand (Optional)
Fig. 3 Equipment sketch
5. The Electronics
The electric control system of ML4030B/ML6045B includes: one master and three slave control
boxes (ML4030B), or five slave control boxes (ML6045B). Each column has one displacement sensor,
one electric hydraulic pump, one microswitch, and one electromagnet.
