Maxima ML4030B - Master Control Box Interface; Slave Control Box Interface

- 6 -
POWER light
“FAULT” light
Emergency button
LCD
Conn ector
Connector
Mode selection knob
Power Switch
“UP” button
“DOWN” button
Fig. 4 Master Control B ox
POWER ligh t
Emergency bu tt on
Conn ector
“FAULT” light
LCD
Connector
“UP” button
Power Switch
“DOWN” button
Fig. 5 Slave Control B ox
