24
Grease and re-insert the pilot valve tappet. During assembly a tangible resistance must be felt
from the previously mounted O ring.
Slip the compression spring onto the pilot
valve tappet.
Insert the USIT ring into the boring.Then tighten the pilot valve screw with a torque of 25Nm.
