MAXIMATOR DLE 5 - Assembly

35
The main parts of the delivery valve are: Inlet socket, valve ball, spring, ball holder, valve
seat and two O rings.
8.3.2 Assembly
8.3.2.1 Outlet valve
Grease the O ring and slip it onto the outlet socket.
Grease the O ring that seals the valve seat and insert the ring in to the HP head.
