3.4 Safety at the place of assembly
MAXIMATOR compressors must not be operated in closed containers, since the
discharged drive air may burst the container.
The high-pressure bolted connections at the suction and pressure sockets must not
be unscrewed, even if this would facilitate the erection of the compressor. The bolted
connections must be firmly tightened in order to avoid any leakages and damage.
The air drive has been designed in such manner that the compressors are safe to be
operated in areas that subject to explosion hazards.
The compressor should be installed in such a manner that the operating elements
and bolted connections are freely accessible at any time.
4 Technical data
Type Pressure ratio
Compression ratio
Admission pressure
Min. Max.
Max.
operating pressure
Turn-of-
piston
volume
Max.
stroke frequency
Threaded connection
Max. operating
temperature Weight
i bar bar cm
3
1/min Inlet
*
Outlet
*
°C kg
(i
1
/i
2
) P
A
P
B
DLE 5
1:5 1:15 2 50 50 746 110 BSP 1/2 BSP 1/2 60 20
4.1 Dimension drawing
