MAXIMATOR DLE 5 - HP Piston Assembly

13
8.1.2 HP piston assembly
Clean all re-used components and inspect them for any damage.
Slightly grease all sealing and guide elements.
Use preferably MAXIMATOR grease Works No. 3610.1456.
Grease the top and bottom cover the O rings that seal the HP part and assemble the rings
(first and second stage).
Attach the HP piston to the piston rod.
Grease the O ring and insert it into the groove between HP piston and piston rod.
