MAXIMATOR DLE 5 - Page 14

14
Grease the O ring and mount it into the HP piston.
Grease the HP cylinder.
Insert the piston sealing ring into the HP
cylinder and align the ring parallel ca. 13 mm
below the cylinder edge.
Push the HP cylinder over the HP piston until
the piston sealing ring fits close to the O ring.
