MAXIMATOR DLE 5 - Page 37

37
Screw the outlet socket into the HP head. Make sure to check before the correct seat of the
ball and the spring. Tighten the outlet socket with 120 Nm.
8.3.2.2 Inlet valve
Grease the O ring and slip it onto the inlet socket.
Grease the O ring that seals the valve seat and slip it onto the valve seat.
