43
Use a small quantity of grease to “glue” the O rings for the sealing between spool valve
housing and top cover into the O ring nests.
Re-attach the spool onto the DLE. During the
process, guide the air pipes into the spool
valve housing.
Place the 4 socket head screws to fasten the
spool valve housingand tighten the screws
with 5 Nm.
