model no. 054-0252-2 | contact us 1-888-670-6682
No. Description No. Description
1 Handle 12 Floor nozzle
2 Safety float valve 13 Foam sleeve / wet filter
3 Filter basket 14 Crevice tool
4 Latch assembly 15 Adaptor
5
30 L (8 U.S. gallons / 6 5/8 Imperial gallons) tank
16 Regular wet/dry cartridge filter
6 Hose inlet assembly 17 Dust bag
7 Drain assembly 18 Utility nozzle
8 Wheel assembly 19 Hose
9 Caster assembly 20 Wire form hose storage on head
10 Electrostatic earth plate 21 Manual
11 Extension tubes (2)
WARNING!
Do not plug in power cord to power outlet. Make sure plug is
disconnected before assembling the Wet/Dry Vacuum.
Ensure that the power cord is
disconnected from the power outlet
。
Lift the top section off the tank.
Undo the clasps.
Remove the contents from inside the
tank .
1
3
2
4
KEY PARTS DIAGRAM
GENERAL ASSEMBLY INSTRUCTIONS
1
2
3
10
12
15 18
13
16 19
14
17
20
11
6
7
4
21
9
8
5
To Next Page
