No. Part No. Description No. Part No. Description
1 2823904000 Quick clamp
assembly
25 5670285000 Pin
2 5610030000 Thread
forming screw
26 3660260000 Torsion spring
3 3127789000 Gear case
cover
27 3402195000 Lever
4 3660375000 Spring 28 3704168000 Clamp
5 3420830001 Bevel support 29 3127791000 Front handle
6 5620399000 Hexagon
socket screw
30 5610044000 Tapping screw
7 5700193000 Oil
impregnated
bearing
31 3550284000 Gear pin
8 3700197000 Washer 32 2824332000 Hook assembly
9 3550169000 Crank roller 33 3660050000 Spring b
10 5700022000 Needle
bearing
34 3700191000 Cap
11 5670186000 Pin 35 5660005000 E ring
12 3704273000 Bearing
clamping plate
36 3402668000 Pendulum lever
set
13 3551281000 Crank roller 37 5660029000 E ring
14 5700025000 Needle
bearing
38 3124150000 Limit plate
15 3700352000 Washer 39 3121057000 Rubber ring
16 5620396000 Screw with
washer
40 3421644900 Gear case
17 2822482000 Gear set 41 3127788000 Handle support
18 5700182000 Needle
bearing
42 5610248000 Tapping screw
19 3402708000 Lever 43 2823930000 Rotor set
20 2823896000 Pivot shoe 44 3121027000 Bearing holder
21 5660027000 Circlips for
shaft
45 3127870000 Fan baffle
22 3127830000 Seal cover 46 5610049000 Tapping screw
23 5610099000 Thread
forming screw
47 2740115000 Stator
24 2824042000 LED assembly 48 3127790000 Motor housing
