Maximum 055-6766-2 User Manual

WARNING!
• Use only 10" (25.4 cm) diameter blades rated at maximum
safe operating speeds of 3500 RPM or higher. Failure to
heed this warning could result in personal injury.
• The blades should always be kept sharp. Use a reputable
sharpening service to sharpen the blades when needed.
• Never store the blades stacked on top of one another.
Place material such as cardboard between them to keep
the blades from coming into contact with one another.
ANTI-KICKBACK PAWLS
Kickback is a hazard in which the workpiece is thrown back toward the operator. The
teeth on the anti-kickback pawls point away from the workpiece. If the workpiece should
be pulled back toward the operator, the teeth dig into the wood to help prevent or
reduce the possibility of kickback.
BEVEL SCALE AND BEVEL INDICATOR
The easy-to-read scale and indicator on the front of the cabinet shows the exact blade
angle.
BLADE GUARD
The guard is installed over the riving knife. It protects the operator’s hand from being cut
while providing a clear view of the material to be cut during through-sawing cuts.
BEVEL-LOCKING LEVER
This lever, under the work table surface on the front of the cabinet, locks the angle
setting of the blade.
No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
Description
Blade guard
Rip fence
Table insert
Rip fence locking handle
Height/bevel adjusting
handwheel
Height adjustment knob
Overload reset switch
Riving knife
Sliding extension table
Rapid position block
Extension table locking lever
Blade wrench
Saw blade and blade wrench
storage
Cabinet
Saw blade
Anti-kickback pawls
Mitre gauge storage
Blade guard storage
No.
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
Description
Anti-kickback pawls storage
Dust extraction port
Rip fence storage
Outfeed support
Mitre gauge groove
Bevel scale
On/Off switch
Safety key
Bevel-locking lever
Front rail
Work table
Bevel indicator
Plug cable
Plug cable storage
Push stick
Push stick storage
Rubber mat
Mitre gauge
Mitre gauge locking handle
Scale
15
model no. 055-6766-2 | contact us 1-888-670-6682
KNOW YOUR TABLE SAW
model no. 055-6766-2 | contact us 1-888-670-6682
14
KNOW YOUR TABLE SAW
SAW BLADE
For maximum performance, it is recommended that you use the 40-tooth, 10" (25.4 cm)
carbide-tipped combination blade provided with your saw. The blade is raised and
lowered with the height/bevel adjusting handwheel. Bevel angles are locked with the
bevel-locking lever.
HEIGHT/BEVEL ADJUSTING HANDWHEEL
Located on the front of the cabinet, this handwheel is used to lower and raise the blade
for adjustments or blade replacement. The handwheel also makes the adjustment for
bevel angles easy.
RIP FENCE LOCKING HANDLE
The handle on the front of the rip fence releases or locks the rip fence with respect to the
work table.
EXTENSION TABLE LOCKING LEVER
This lever, under the work table surface, locks the right extension table.
RUBBER MAT
To better protect the left side of the work table with rubber feet when storing the table
saw vertically.
RAPID POSITION BLOCK
Rapidly set the rip fence to 14” (355.6 mm) on the right rail with it, and more easily read
the extended length.
MITRE GAUGE
This mitre gauge aligns the wood for a cross cut. The easy-to-read indicator shows the
exact angle for a mitre cut.
MITRE GAUGE GROOVES
The mitre gauge rides in these grooves on either side of the blade.
FRONT RAIL
Front rail provides support for the rip fence.
