NOTICE:
◎
Please refer to the above process parameters for stack welding, fillet welding, lap
welding, etc.
Handheld laser welding process parameter table - wire feeding
Material
Material
thickness
wire
feed
speed
Laser
power
percentage
Scanning
width
Scanning
frequency
Defocus
amount
Air flow
volume
Welding
consumables
Wire
diameter
Welding
effect
mm mm/s % mm HZ mm L/min / mm Penetration
Carbon
Steel
(Q235B)
1 12~15 85% 2 40~80 1~-1 15~20
Stainless
steel
0.8-1.0 Penetration
2 8~10 100%/D4 2 40~80 1~-3 15~20
Stainless
steel
0.8-1.0 Penetration
Stainless
steel
(SUS304)
1 12~18 85%% 2 40~80 1~-1 15~20
Stainless
steel
0.8-1.2 Penetration
2 8~10 100%/D4 2 40~80 1~-3 15~20
Stainless
steel
0.8-1.2 Penetration
Galvanized
sheet
1 12~18 85% 2 40~80 1~-1 15~20
Stainless
steel
0.8-1.0 Penetration
2 8~10 100%/D4 2 40~80 1~-3 15~20
Stainless
steel
0.8-1.0 Penetration
Aluminum
alloy
(Al6061)
1 12~18 95% 2 40~80 1~-1 15~20
Aluminum
alloy
0.8-1.0 Penetration
2 12~15 100%/D4 2 40~80 1~-3 15~20
Aluminum
alloy
1.0 Penetration
Remark
1, the welding form is splicing welding, welding head ratio of 66:120,800 W laser fiber core diameter of 20
microns;
2, welding protective gas: stainless steel - nitrogen (purity 99.99%), other materials - argon (purity 99.99%);
3. The power percentage is 10-100%, the swing amplitude is 0-4mm (2-3mm is recommended), the swing
frequency is 0-220hz (40-80hz is recommended for manual welding, and the gas flow rate is 15-20L/min). Under
the condition that other parameters remain unchanged, the swing amplitude or welding speed increases, and the
laser power also needs to increase accordingly;
4, the wire feed machine needs to adjust the wire feed speed, by adjusting the pressure of the wire feed wheel,
in the automatic mode, the wire feed speed is uniform, smooth wire feed, no lag phenomenon;
5. D mode enabling condition: D mode can be enabled if the power is ≥90%
Process parameters are adjusted according to the actual wire material and wire diameter
6. Due to the different equipment configuration (wire feeding machine differences) and welding methods (wire
feeding speed, air pressure, degree of deflection, welding Angle) adopted by different customers, this data is
for reference only.
NOTICE:
◎ Please refer to the above process parameters for stack welding, fillet welding, lap
welding, etc.
65
