MAXPhotonics MFP-100W User Manual

15
Chapter 4
Specification
1-
Optical Characteristic Parameters
NO. Characteristics Test Conditions Min. Typical Max. Unit
1 Mode Pulse
2 Polarization Random
3 Beam Quality M
²
Pout=Pnom 2.0
4 Center Wavelength Pout=Pnom 1060 1064 1070 nm
5
Spectrum
Width(3dB)
Pout=Pnom 8 nm
6
Average Optical
Power(Pnom)
25℃ MFP-100W 95 100 105 W
25℃ MFP-200W 195 200 205 W
25℃ MFP-300W 295 300 305 W
7 Power Range 10 100 %
8
Single pulse
energy
1.5 mJ
9
Optical Pulse
Width(FWHM)
100w@67KHz 90 110 130 ns
200w@133KHz 120 140 160 ns
300w@200KHz 140 160 180 ns
10
Pulse Repetition
Frequency (PRF.)
MFP-100W 20 200
KHzMFP-200W 20 230
MFP-300W 50 350
11
Full-Power
Frequency
100W 65 200
KHz200W 135 230
300W 200 350
12
Output Power
Stability
Pout=Pnom 5 %
