MAXPhotonics MFP-5W User Manual

15
Chapter 4
Specication
1-
Optical Characteristic Parameters
NO. Characteristics Test Conditions Min. Typical Max. Unit
1 Mode Pulse
2 Polarization Random
3 Beam Quality M²
MFP-5W/10W/20X/
20W/30X
1.2 1.4 1.5
MFP-20H/30W/30H
/50W/50X/50H/70W
1.3 1.6 1.8
4 Center Wavelength Pout=Pnom 1060 1064 1070 nm
5 Spectrum Width(3dB) Pout=Pnom 5 5 10 nm
6
Average Optical
Power(Pnom)
MFP-5W 4.5 5 5.5
W
MFP-10W 9.5 10 10.5
MFP-20X 18 18.5 19
MFP-20W/H 20 20.5 21
MFP-30X@40K 29 29.5 30
MFP-30X@30K 24 25 26
MFP-30W/H 29 30 31
MFP-50W/H/X 49 50 51
MFP-70W 69 70 71
7 Power Range 10 100 %
8 Single pulse energy
MFP-5W 0.5
mJ
MFP-10W 0.45
MFP-20W/20X/30X 0.65 0.68 0.75
MFP-
20H/30W/50W/50X
1
MFP-30H/70W/50H 1.4 1.45 1.5
