MAXPhotonics MFP-5W User Manual

27
Chapter 5 Operation Guide
Pin21 outputs the corresponding alarm signal. If the temperature drops below
+ 45 ° C, the laser will not automatically resume working, and keep the alarm
signal unchanged, restart the operation.
4-Common Boards And Parameter Settings
MFP acousto-optic Q-switched ber lasers reect high-speed and high-efciency
capabilities, so it is required to congure high-speed galvanometers as much as
possible to reect their performance advantages.
name of
software
SAMlight
NO. Name / Item
Set parameter value Typical setting value
unit
1 Empty pen delay 50
～
100 Us
2 Pen delay 50
～
100 Us
3 Turning delay 50
～
100 Us
4 Laser delay -60
～
-150 Us
5 Laser Delay Off 60
～
150 Us
name of
software
EzCad
（
bjjcz
）
NO. Name / Item
Set parameter value Typical setting value
unit
1 End delay 50
～
150 Us
2 Corner delay 50
～
150 Us
3 Laser delay -50
～
-200 Us
4 Laser Delay Off 20
～
150 Us
5 Laser Delay Off 60
～
150 Us
name of
software
MAX software
NO. Name / Item
Set parameter value Typical setting value
unit
1
Empty pen delay
50 ～ 100 Us
2
Marking delay
50 ～ 100 Us
3
Turning delay
20 ～ 100 Us
4
Laser delay
-50 ～ -200 Us
5
Laser Delay Off
50 ～ 150 Us
Recommended Supporting Models For Common Field Lenses
Field
lens focal
length
20X 20W 20H 30X 30W 30H 30H 50X 50W 50H 70W
