MAXPhotonics MFSC-1500X G4.0 Series User Manual

21
Chapter 4
Specification
1 -Optics Characteristic Parameters
No. Characteristics Test conditions Min. Nom. Max. Unit
1 Operation mode CW/Modulated
2 Polarization Random
3
Output power
MFSC-1000X(G4.0)
100% CW 1000
W
Output power
MFSC-1500X (G4.0)
100% CW 1500
4 Tuning range of output power 10 100 %
5 Emission wavelength 100% CW 1070 1080 1090 nm
6 Spectrum width(3dB) 100% CW 3 5 nm
7 Short-term power instability 100% CW>1h ±1 ±1.5 %
8 Long-term power instability 100% CW>24h ±2 ±3 %
9 Beam quality BPP 50um-QBH Output 1.5
mm x
mrad
10 Laser switching ON time 10%→90%Output 50 100 μs
11 Laser switching OFF time 90%→10%Output 50 100 μs
12 Modulation rate 100%Output 20 KHz
13 Red guide laser power 100%Output 200 μW
14
Feeding fiber cable length
MFSC-1000X(G4.0)
10
（
5
、
15 optional
）
m
Feeding fiber cable length
MFSC-1500X(G4.0)
15
（
5
、
10 optional
）
15 Feeding fiber core size 50 μm
16
Feeding fiber cable bending
radius
200 mm
17 Output form Standard QBH
（
LOC
）
